CPE Film Cast PE Wrap
CPE film is a cast-produced film primarily composed of polyethylene. This film has great features. It seals tightly, handles many temperatures, creates low static electricity, and resists corrosion. Custom printing services are available, with high transparency enhancing packaging aesthetics. Applications are extensive, covering food packaging, industrial protective films, and agricultural mulch films. We are a Chinese manufacturer and supplier of CPE film. We use production lines to make high-quality film. This helps keep prices low and cuts procurement costs.
Featuers：
- Highly sealed: Waterproof, moisture-proof, and airtight
- Wide temperature range: -8 to 100°C
- Custom printing services available
- Low haze, safe for direct food contact
Product Details of CPE Film
CPE film is a type of plastic film, also known as co-extruded polyethylene film. This film is produced using a casting process that demands strict manufacturing techniques. Typically, one side undergoes corona treatment while the other side enhances sealing performance.
Its robust properties include the following:
- Strong sealing capability, waterproof and moisture-resistant, makes it suitable for packaging materials. High puncture resistance and wear resistance provide excellent product protection.
- Superior optical properties with high gloss and transparency.
- It shows how the product looks. This makes it great for packaging fresh fruits and vegetables.
- It exhibits strong chemical stability, as well as resistance to heat and corrosion. It finds extensive applications in industrial and agricultural sectors. Common uses include packaging bags for chemical products and anti-static packaging for electronics.
- CPE film is frequently laminated with other materials. Common laminates include nylon, PET, and PP. It can be a heat-sealing layer. This improves the packaging’s sealing and anti-static properties.
The cooling stage is critical in CPE film production. We tightly control temperatures on our production line. This ensures the films reach their best performance. Film parameters are adjustable, offering many style options. We offer pattern printing and custom production tailored to customer requirements. We provide competitive prices that fit your production needs. We also deliver great service.
Product Catalog
Contact Us
Specifications:
| Parameter | Specification |
|---|---|
| Thickness (μm) | 15-150, customizable |
| Length (m) | 300, customizable |
| Width (mm) | 130-3500, customizable |
| Core Diameter | 3” / 6”, customizable |
| Material | PE (Polyethylene) / PP (Polypropylene) |
| Technology | Casting |
| Color | Transparent, Blue, Black |
| Finish | High Gloss, Matte |
| Printing Method | Gravure Printing |
| Surface Treatment | One side corona treated, one side smooth |
| Production Method | OEM/ODM |
| Transportation Method | Pallet Transportation |
| Shipping Port | Shanghai Port, Guangzhou Port, Hong Kong Port |
Technical Specifications:
| Property | Specification |
|---|---|
| Density (gm/cc) | 0.91 |
| Haze (%) | 3.3 – 8 |
| Tensile Strength at Break MD (MPa) | 45.0 – 72.0 |
| Tensile Strength at Break TD (MPa) | 30.0 – 37.0 |
| Elongation at Break MD (%) | 678.7 – 697.3 |
| Elongation at Break TD (%) | 771.3 – 800.2 |
| Heat Seal Temperature (°C) | 122 – 131 |
| Heat Seal Strength (N/15mm) | ≥ 10.3 |
| Temperature Resistance (°C) | -8 to 100 |
| Corona Treatment Level (dyne/cm) | 38 |
| Coefficient of Friction (COF) Dynamic | 0.125 – 0.185 |
| Coefficient of Friction (COF) Static | 0.120 – 0.190 |
Advantages:
- High Temperature Resistance: Withstands extreme cold and heat; suitable for diverse applications.
- Strong heat sealing performance: Enables effortless heat-sealing operations.
- Excellent chemical stability: resists corrosion; ideal for complex environments.
- Safe and Non-Toxic: Meets food-grade standards; safe for direct food contact.
- Low Static Electricity: Anti-static properties suitable for packaging electronics.
- Strong sealing: waterproof and moisture-proof; extends product shelf life.
- Mechanized Production: Boosts efficiency and reduces labor costs.
- High Aesthetic Appeal: Customizable printing enhances packaging aesthetics.
- High Toughness: Strong tensile strength with elastic recovery.
- High Strength: Excellent puncture resistance minimizes damage.
- Superior Optical Properties: High transparency and glossiness for product visibility.
- Soft Texture: Flexible packaging conforms to irregularly shaped items.
- Environmentally Friendly: Production processes minimize emissions; recyclable separately from other plastics.
Application:
Food Sector: Wide temperature tolerance range, customizable printing, and aesthetically pleasing.
- Frozen Foods: Quick-frozen items, seafood, and fresh meat.
- Vacuum-cooked packaging: instant soup pouches, pasteurized milk, and vacuum-packed rice.
- Snack packaging: candies, milk tablets, and cookies.
- Fresh Produce: Food preservation film.
Household Applications: High transparency for product display and strong sealing for product protection.
- Personal Care: Shower gel, shampoo.
- Cosmetics: skincare products, makeup.
Industrial Applications: High puncture resistance, moisture proof, and corrosion resistant.
- Construction Industry: Moisture-proof film, protective film.
- Chemical Industry: Anti-corrosion protective film, fertilizer packaging, and equipment protective films.
- Electronics Industry: Anti-static protective film, electronic component packaging.
- Manufacturing Industry: Automotive window protective film, glass window protective film.
- Agricultural Applications: Strong sealing, blacklight blocking.
- Used as ground cover film, greenhouse film, and crop protection film.
Related product:
Food CPE Packaging Film: Works well in a wide range of temperatures. It’s perfect for low-temperature quick-frozen foods. Features moderate shrinkability and is also applicable for vacuum high-temperature sterilization packaging. FDA-certified, non-toxic, and odorless.
Agricultural CPE Mulch Film: Nurtures planting soil, retains moisture. Stops weed growth when used as ground cover. It also helps in greenhouses by resisting wind and preventing lodging.
Electronic Protective Film: Further enhances anti-static properties. Ensures safer, more reliable packaging for electronic components. Prevents scratches on components and screens; high performance and excellent cost-effectiveness.
